Skutan - A roof box for everyone
(2024) IDEL01 20221Industrial Design
- Abstract
- A roof box is an essential part of a skiing trip by car, but many users find it frustrating and time consuming to use. Interviews with users showed that they find it difficult to load and unload the roof box, since it is too high up for most people. They also expressed that it is too heavy to lift the skis above their heads and that they find it problematic that they are not able to see the inside. Market research showed that current manufacturers have not addressed these issues and therefore have missed the opportunity to create a valid solution to the problems that their users experience. During the ideation phase of the design process, I attempted to find a new way of accessing the skis in a roof box by sketching, building a mockup,... (More)
- A roof box is an essential part of a skiing trip by car, but many users find it frustrating and time consuming to use. Interviews with users showed that they find it difficult to load and unload the roof box, since it is too high up for most people. They also expressed that it is too heavy to lift the skis above their heads and that they find it problematic that they are not able to see the inside. Market research showed that current manufacturers have not addressed these issues and therefore have missed the opportunity to create a valid solution to the problems that their users experience. During the ideation phase of the design process, I attempted to find a new way of accessing the skis in a roof box by sketching, building a mockup, testing and finding out users' opinions on what I had created. The result of the project was Skutan, a roof box where the skis and ski poles are mounted in holders on a platform that is tilted and slides down to the user for easy access. The construction is based on established mechanical technologies, such as pneumatic cylinders, that use raised air pressure to tilt the platform to alleviate physical effort for the user. Skutan offers a completely new accessibility for its users, ensuring an easy and comfortable experience regardless of the user’s height. (Less)
- Popular Abstract
- A roof box can be a skier’s best friend, allowing storage for the valuable skiing equipment when traveling by car. Unfortunately, the majority of roof box users can not use it the intended way. The biggest problem for many users, is that the roof box is too far up to reach the contents inside. Even people who are tall enough experience a lot of obstacles in the process. The fact that it is difficult to use a roof box is an issue that we have come to accept without further reflection. Some people are not even able to use it. It is time to think of a way to solve this problem.
Skutan offers a completely new accessibility for its users, making the process of loading and unloading the skis an easy and comfortable experience.
The skis... (More) - A roof box can be a skier’s best friend, allowing storage for the valuable skiing equipment when traveling by car. Unfortunately, the majority of roof box users can not use it the intended way. The biggest problem for many users, is that the roof box is too far up to reach the contents inside. Even people who are tall enough experience a lot of obstacles in the process. The fact that it is difficult to use a roof box is an issue that we have come to accept without further reflection. Some people are not even able to use it. It is time to think of a way to solve this problem.
Skutan offers a completely new accessibility for its users, making the process of loading and unloading the skis an easy and comfortable experience.
The skis and ski poles are placed in holders to create an even distribution of the weight. The skis will be easy to organize and stay in place, which will protect them from damage. The holders are mounted to a platform in the bottom of the box. This platform is lifted to a 55° angle by using simple pneumatic mechanics. The skis then gently slide down to a position where the user easily can access the skis. This also eliminates the need to lean against the car, keeping your ski clothes from getting dirty.
Using Skutan is more efficient, giving you time for what really matters.
Skiing. (Less)
Please use this url to cite or link to this publication:
http://lup.lub.lu.se/student-papers/record/9150675
- author
- Holmer, Elin LU
- supervisor
- organization
- alternative title
- Skutan - En takbox för alla
- course
- IDEL01 20221
- year
- 2024
- type
- M2 - Bachelor Degree
- subject
- keywords
- Industrial design, design, product design, roof box, skiing, ski, car, user-centered design, automotive design, transportation design, ergonomics, user needs, roof box design, market research, design iterations, design process, sketching, prototyping, CAD, innovation
- other publication id
- ISRN: LUT-DVIDE/EX--24/50675-SE
- language
- English
- id
- 9150675
- date added to LUP
- 2024-09-23 12:02:06
- date last changed
- 2024-09-23 12:02:06
