Parametrisk design av vindkraftverks fundament genom automatiserad modellering.

Holst Sneckenborg, Emil LU (2024) In TVSM-5000 VSMM01 20241
Structural Mechanics
Department of Construction Sciences
Abstract
The escalating concerns surrounding climate change have intensified the focus on the renewable energy market, with initiatives aimed at energy security, CO2 emissions reduction, and sustainability. Wind turbines, considered a key component of renewable energy solutions, have seen significant investment growth globally. However, challenges persist, including the environmental impact of construction and economic factors affecting profitability. This thesis aims to address these challenges by developing an automated script for wind turbine foundation design, contributing to streamlining processes in the renewable energy sector.

In the development of the script the API documentation for SAP2000 has been utilized to automate the modeling of... (More)
The escalating concerns surrounding climate change have intensified the focus on the renewable energy market, with initiatives aimed at energy security, CO2 emissions reduction, and sustainability. Wind turbines, considered a key component of renewable energy solutions, have seen significant investment growth globally. However, challenges persist, including the environmental impact of construction and economic factors affecting profitability. This thesis aims to address these challenges by developing an automated script for wind turbine foundation design, contributing to streamlining processes in the renewable energy sector.

In the development of the script the API documentation for SAP2000 has been utilized to automate the modeling of the foundation. The foundation is modeled with thick
area elements to replicate the sloped geometry and properties of the foundation. FEM-analysis for different load cases was performed on the model in order to output sectional moments, normal and shear forces. The forces were used in order to design required reinforcement in the radial and tangential direction at the top and bottom edges of the foundation. This was performed with the sandwich model. Further, design of required shear reinforcement was incorporated into the script. As a result, the script outputs required reinforcement in tangential, radial and shear direction to guarantee structural integrity. Fatigue assessment was carried out using Markov matrices to verify that the cumulative damage of is below the value of 1.

The foundation design has not examined the impact of the anchor cage. Only simplifications of constraining it as a rigid body has been carried out. This implies that a more thorough analysis of the anchor cage’s impact on the foundation is necessary before relying fully on the script’s results.

Simpler calculations for the bearing and sliding capacity, along with overturning risk,
were conducted based on established guidelines. Consequently, the modeling primarily
emphasizes the behavior of the foundation rather than the soil itself. (Less)
Popular Abstract
Climate change has heightened the focus on the renewable energy market. Initiatives aimed at reducing CO₂ emissions have made sustainable energy production one of today’s greatest challenges. The question of how to generate electricity sustainably has become a prominent political debate. Among the various approaches, wind turbines stand out, having recently undergone significant technological advancements. Despite the improvements, the expansion of wind power
lacks efficiency. Automating the modeling phase could be a key piece of the puzzle, enablingquicker production of drawings and dimensions for deployment.
