Design of analog audio filters for individual speaker models in a distributed system

Saranpää, William LU and Alveteg, Simon LU (2025) EITM01 20251
Department of Electrical and Information Technology
Abstract
This thesis investigates the performance and feasibility of passive and active analog frequency compensation filters for audio signal processing in a distributed
speaker system. One passive and one active circuit topology were investigated
more thoroughly and then the active filter was realized on a PCB and evaluated
with electrical, thermal and acoustic measurements.

The work also resulted in two methods of designing frequency compensating
or equalizing filters based on active or passive filters respectively. The design was
partly automated with the use of optimizing algorithms that integrated with a
LTSpice model of different circuits. The active filters were based on a constant-
Q graphic equalizer topology, and performed... (More)
This thesis investigates the performance and feasibility of passive and active analog frequency compensation filters for audio signal processing in a distributed
speaker system. One passive and one active circuit topology were investigated
more thoroughly and then the active filter was realized on a PCB and evaluated
with electrical, thermal and acoustic measurements.

The work also resulted in two methods of designing frequency compensating
or equalizing filters based on active or passive filters respectively. The design was
partly automated with the use of optimizing algorithms that integrated with a
LTSpice model of different circuits. The active filters were based on a constant-
Q graphic equalizer topology, and performed better than the passive bridged-T
based topologies in relation to flattening the speaker's frequency response. The
passive filters had less power dissipation and produced less noise than their active
counterparts, at the expense of lower selectivity as well as a lower output volume
due to the added insertion loss. The design of the active filters was also quicker
and gave more reliable results.

The filters were evaluated on two different speakers with different frequency
responses in order to ensure the generality of the method. The passive filters could
reduce the average deviation from 3.52 dB to 1.68 dB for speaker 1 and from 2.64
dB to 1.58 dB for speaker 2, while the active filter with 16 filter sections could
reduce it to 1.57 dB for speaker 1 and 0.82 dB for speaker 2. Further reduction is
most likely possible, as manual adjustment of just five filter sections brought the
average deviation down from 1.75 dB to 1.63 dB for speaker 1.

Analog filters are a viable option for applications where the power budget, cost
or limitations in signal availability or routing pose challenges. The method created
simplifies the design process of equalizing filters and reduces the engineering time
needed. (Less)
