Automatisk generering av transportytor för 3D-stadsmodeller enligt 3CIM-specifikationen

Hellsten, Justin LU (2025) In Examensarbete i geografisk informationsteknik EXTM05 20251
Dept of Physical Geography and Ecosystem Science
Abstract (Swedish)
This thesis explores the possibilities of integrating semantic transport information in the context of 3D-city modelling by implementing transport surfaces according to standards defined by the 3CIM specification, an extension of CityGML. This approach aims to automatically generate transport surfaces in LOD1 and LOD2, based on the Stockholm city basemap in combination with road geometries that represent roads taken from NVDB. In extension, it also aims to divide the road network into sections and intersections based on CityGML3, which further expands the 3CIM information model. By generating these transport surfaces, they can act as the foundation for digital twins of cities and therefore have plenty of areas of usage.
A central goal... (More)
This thesis explores the possibilities of integrating semantic transport information in the context of 3D-city modelling by implementing transport surfaces according to standards defined by the 3CIM specification, an extension of CityGML. This approach aims to automatically generate transport surfaces in LOD1 and LOD2, based on the Stockholm city basemap in combination with road geometries that represent roads taken from NVDB. In extension, it also aims to divide the road network into sections and intersections based on CityGML3, which further expands the 3CIM information model. By generating these transport surfaces, they can act as the foundation for digital twins of cities and therefore have plenty of areas of usage.
A central goal was to evaluate whether a generalized, repeatable and automatic method could be developed. The process makes use of one training area and two test areas with varying data quality. Results show that the approach is capable enough to produce useful outputs even from low-quality input data. Working around poor data, like an incorrect basemap and poorly defined line objects in the NVDB, it still offers key learnings when investigating an automatic process for the topic. Even though the results show potential, a fully automatic process is still unattainable due to large variations in quality in the basemap. The thesis offers several recommendations for both the basemap and the overall process, and concludes that further work on the topic is not only recommended but likely essential. (Less)
Popular Abstract (Swedish)
Tänk dig att kunna visualisera bullernivåer, simulera trafikflöden eller utvärdera stadsförändringar digitalt – innan en enda spade satts i marken. Med hjälp av digitala tvillingar av städer blir detta möjligt, med det kräver detaljerade 3D-modeller av våra städer. Detta examensarbete undersöker om det går att skapa underlag till dessa modeller, utan att behöva mäta varje gata för hand. Istället, undersöks andra alternativ som att utnyttja redan befintlig information om stadens form och innehåll för att skapa dessa modeller.
Please use this url to cite or link to this publication:
author
Hellsten, Justin LU
supervisor
organization
course
EXTM05 20251
year
type
H2 - Master's Degree (Two Years)
subject
keywords
Digital twins, 3D-city models, CityGML, 3CIM, Level of detail, Application domain extension
publication/series
Examensarbete i geografisk informationsteknik
report number
Nr 42
language
Swedish
id
9204884
date added to LUP
2025-06-25 12:51:47
date last changed
2025-06-25 12:51:47
