Position tracking of optical modules in multidirectional network cameras by using ultrasonic waves

Waldén, Gustaf LU and Rydberg, Linnéa (2024) In CODEN:LUTEDX/TEIE EIEM01 20241
Industrial Electrical Engineering and Automation
Abstract
In products with multiple, movable components it is often important to know
the position of them. Such an example is to localize the different optical modules used within a multidirectional surveillance camera. This thesis explores
the feasibility of using ultrasound distance-measuring technology for that particular application. Various methods and technologies were examined before
developing a concept that utilises commonly used piezoelectric transducers in
conjunction with time of flight distance measurements.
A prototype was constructed based on this concept, aiming to investigate the
limitations and capabilities of this approach. In parallel, a signal processing
algorithm was implemented to acquire accurate distance... (More)
In products with multiple, movable components it is often important to know
the position of them. Such an example is to localize the different optical modules used within a multidirectional surveillance camera. This thesis explores
the feasibility of using ultrasound distance-measuring technology for that particular application. Various methods and technologies were examined before
developing a concept that utilises commonly used piezoelectric transducers in
conjunction with time of flight distance measurements.
A prototype was constructed based on this concept, aiming to investigate the
limitations and capabilities of this approach. In parallel, a signal processing
algorithm was implemented to acquire accurate distance measurements. The
prototype’s accuracy in determining distance and position was thoroughly
tested, revealing a positional accuracy within ±8°. The performance of the
prototype was evaluated, highlighting its strengths and limitations. Finally,
recommendations for future work are proposed to further enhance the system’s
accuracy and reliability. (Less)
Please use this url to cite or link to this publication:
author
Waldén, Gustaf LU and Rydberg, Linnéa
supervisor
organization
course
EIEM01 20241
year
type
H3 - Professional qualifications (4 Years - )
subject
publication/series
CODEN:LUTEDX/TEIE
report number
5522
language
English
id
9177124
date added to LUP
2024-11-07 17:00:27
date last changed
2024-11-07 17:00:27
