Automation and simulation of a robot cell for stud bolt welding

Ljunglöv, Elias LU (2025) In CODEN:LUTEDX/TEIE EIEM01 20251
Industrial Electrical Engineering and Automation
Abstract (Swedish)
The importance of sustainable and effective energy usage is rapidly growing. SWEP International AB leads the manufacturing of brazed plate heat exchangers that offer effective heating and cooling applications used in various systems and industries. Stud bolts are manually welded onto the heat exchanger surface in their manufacturing process. A project to fully automate this process using an industrial robot has already begun at SWEP to increase the process productivity, quality, and
repeatability. The idea is to use a robot with an attached touch probe to measure points on the surface and sides of a heat exchanger in high precision to calculate a center reference point and account for any slight rotational offset. Then, the same robot... (More)
The importance of sustainable and effective energy usage is rapidly growing. SWEP International AB leads the manufacturing of brazed plate heat exchangers that offer effective heating and cooling applications used in various systems and industries. Stud bolts are manually welded onto the heat exchanger surface in their manufacturing process. A project to fully automate this process using an industrial robot has already begun at SWEP to increase the process productivity, quality, and
repeatability. The idea is to use a robot with an attached touch probe to measure points on the surface and sides of a heat exchanger in high precision to calculate a center reference point and account for any slight rotational offset. Then, the same robot uses an attached weld gun to weld stud bolts onto the surface. This thesis aimed to continue their project of creating a fully automated solution to eventually
replace the manual bolt welding station with an automated robot cell solution. (Less)
Please use this url to cite or link to this publication:
author
Ljunglöv, Elias LU
supervisor
organization
course
EIEM01 20251
year
type
H3 - Professional qualifications (4 Years - )
subject
keywords
stud bolt welding, automated welding, brazed plate heat exchangers, PLC, HMI, IRC, ABB RobotStudio, Siemens TIA Portal, Tecnomatix Plant Simulation
publication/series
CODEN:LUTEDX/TEIE
report number
5532
language
English
id
9187165
date added to LUP
2025-04-18 10:34:23
date last changed
2025-04-18 10:34:23
